5 Channel A/V Amplifier
Specifications
| PREAMPLIFIER | ||
| Maximum Output (<0.1% THD) | 3.5 Vrms, subwoofer channel 6.1 Vrms | |
| Frequency Response (2 Vrms output) | 8 Hz to 28 kHz (+0, -0.25 dB) | |
| Frequency Response, Analog-Direct mode (2 Vrms output) | 8 Hz to 50 kHz (+0, -0.25 dB) | |
| THD+N (2 Vrms output) | <0.03% | |
| S/N Ratio (2 Vrms output, IEC-A filter) | 102 dB | |
| L-R channel separation (analog input, 1 kHz) | 96 dB | |
| PREAMPLIFIER + AMPLIFIER | ||
| Frequency Response (full power output) | 10 Hz to 30 kHz (+0, -0.5 dB) | |
| THD+N (1W output) | <0.04% (20 Hz to 20 kHz) | |
| S/N Ratio (full power output, IEC-A filter) | 101 dB | |
| AMPLIFIER | ||
| Maximum continuous output into 8 ohms, 20 Hz to 20 kHz, 0.1% THD: | ||
| MRX 710 | 120 W (2 channels driven), 90 W (5 channels driven) | |
| MRX 510 | 100 W (2 channels driven), 75 W (5 channels driven) | |
| MRX 310 | 80 W (2 channels driven), 60 W (5 channels driven) | |
| POWER REQUIREMENT | ||
| Maximum continuous output into 8 ohms, 20 Hz to 20 kHz, 0.1% THD: | ||
| 120 V version: | In countries where the line voltage is 120 V, this product operates from a single phase AC power source that supplies between 108 V and 132 V at a frequency of 60 Hz. | |
| 220-240 V version: | In countries where the line voltage is 220, 230, or 240 V, this product operates from a single phase AC power source that supplies between 198 V and 264 V at a frequency of 50 Hz. | |
| CONSUMPTION | ||
| Maximum | 500 W (MRX 710/510), 400 W (MRX 310) | |
| Standby (default ECO mode) | <0.3 W | |
| Standby IP Control enabled | 2.0 W (1.8 W if network cable is not connected) | |
| Standby HDMI Bypass enabled | 5.6 W | |
| Standby IP Control and Standby HDMI Bypass enabled | 6.6 W | |
